Single-Jaw Portable Ground Resistance Tester

Name: Single-Jaw Portable Ground Resistance Tester
Brand: Xi'an Xu&Hui Electromechanical Technology Co., Ltd.
SKU: XHDQ703
Price: 440.00 USD
Availability: InStock

製品詳細:

起源の場所:	中国・陝西省西安
ブランド名:	XZH TEST
証明:	ISO CE
モデル番号:	XHDQ703

詳細情報

起源の場所:

中国・陝西省西安

ブランド名:

XZH TEST

証明:

ISO CE

モデル番号:

XHDQ703

電源:

DC6V（単3形アルカリ電池×4本）

ハイライト:

High Light

ハイライト:

Single-Jaw Ground Resistance Tester

High Precision Ground Tester

Portable Earth Resistance Tester

Trading Information

最小注文数量:

1セット

パッケージの詳細:

木製梱包

受渡し時間:

5～8営業日

供給の能力:

3000台/年

製品の説明

Product Overview

The XHDQ703 Single-jaw Earth Resistance Tester is widely applied to measure earth resistance and loop resistance for electrical equipment in power, meteorology, oilfield, construction and industrial sectors. When measuring earthed systems with loops, it requires no disconnection of earth down-leads or auxiliary electrodes. This tester is capable of detecting earth faults that cannot be measured by traditional methods and is suitable for scenarios where conventional measurement approaches are inapplicable. The XHDQ series clamp-on earth resistance testers measure the combined value of earth electrode resistance and earth lead resistance.

Performance Features

★Functions: Earth resistance test, loop resistance test;

★Start-up time: Self-test completed in only 0.5 seconds, finished instantly upon power-on;

★Automatic interference signal identification and automatic gear shifting;

★Acousto-optic alarm, equipped with RS232 interface;

Single-Jaw Portable Ground Resistance Tester 0

Technical Specifications
☆ Power Supply: 6V DC (4 x AA alkaline batteries)
☆ Resistance Range: 0.01 – 1200 Ω; Accuracy: ±1% ±0.01 Ω; Resolution: 0.001 Ω
☆ LCD Display: 4-digit digital LCD
☆ Data Storage: 99 sets
☆ Operating Temperature & Humidity: -20°C – 55°C; 20% RH – 90% RH
☆ Jaw Dimensions: 65 mm × 32 mm
☆ Jaw Opening: 32 mm
